The Yamaha YRM20 is a high - end, efficient, and versatile pick - and - place machine launched by YAMAHA, standing out as a flagship product in the company's lineup. Here is a detailed introduction:
1. High - speed and Versatile Head System
- Ultra - high - speed Rotary RM Head: It is equipped with a rotary - type head that can improve the placement performance of small chip components. Inheriting the advantages of the "single - head solution", it eliminates the need for head replacement. This head can support a wide range of component placements, from 0201mm ultra - small chip components to 12×12mm, 6.5mm - high medium - sized and irregular components, achieving a placement capacity of up to 115,000CPH.
- High - speed Universal Inline HM Head: This is a versatile head with both high - speed and general - purpose characteristics. It can handle components ranging from 0201 ultra - small components to 55×100mm, 15mm - high large components. When combined with the RM head, it can achieve high - speed placement of all - sized components.
2. Advanced Technological Features
- Cross - zone Operation Ability: By adopting the cross - zone running technology from the Σ series products, the interference area between the two existing placement heads is minimized, further enhancing the production efficiency of the machine.
- Special - structured ZSR High - speed Feeder: This feeder is suitable for the high - production - rate RM head. Its use significantly increases the conveying speed of components and supports the ultra - high - speed suction of the RM head.
3. Other Outstanding Features
- Dual - conveyor System: The dual - conveyor system has been further improved, greatly enhancing the substrate compatibility (with a maximum substrate width of up to 510mm). It also enables high - speed conveyance and significantly shortens the substrate replacement time.
- Low - impact Suction Nozzle for High - quality Placement: Standard - equipped with a lightweight suction nozzle necessary for the small - pitch placement of ultra - small components, it can achieve high - speed, low - impact placement. Moreover, the nozzle has a complete ID, which improves maintainability.
- Vision System for Improved Placement Quality: The component recognition camera can be flexibly switched between production - line photography mode and area photography mode. Additionally, a side - view camera is provided to enhance the placement quality of small components. A coplanarity detection device can also be optionally equipped.
- Nozzle Maintenance and Feeder Maintenance Warning Function: Through self - diagnosis and self - repair functions, the suction nozzle and feeder can be kept clean, maintaining high - quality production.
- Auto - replenishment Feeder: It supports the preset system of auto - replenishment feeders, which disperses the component supply and reduces the workload of operators.
preparation function, it can greatly reduce the workload during product - type changes.
In conclusion, the Yamaha YRM20 is a high - speed, high - precision, and highly productive pick - and - place machine with advanced technology and strong market competitiveness, suitable for various substrate placement needs in the electronics manufacturing industry.
